PA30° DIN5480 Involute Spline Gear Hob Cutter with Module m2.5
2022-06-01 08:49:31
jiangxingTools
3166
PA30° DIN5480 Involute Spline Gear Hob Cutter with Module m2.5
Tooth profile：GB, DIN5480 standard
Material：HSS M2, M35,ASP2052, S390
Accuracy：AA, A DIN3968
Hob sizes：OD 60 * Length 60 * Bore 27mm
Module m2.5, with pressure angle PA30°
