PA20° DIN3972 Standard DP Gear Hob
2022-05-19 09:25:49
jiangxingTools
2336
PA20° DIN3972 Standard DP Gear Hob
Tooth profile is according to GB, DIN3972-2 standard
Material is HSS M2, M35, S390
Accuracy：class AA, A
Module/Diametral Pitch DP3, DP3.5, DP4, DP4.5, DP5,DP6, DP7,DP7, DP8, DP9, DP10,DP11,DP12,DP1,DP16, DP18, DP20,DP22,DP24
Hob bore：22mm, 27mm ,32mm
Condition：gear hob for finishing, pre-shaving, pre-grinding
